Pressure Sensor BMP384
Gel-filled package. Robust. Media resistant.
BMP384
Pressure sensor
BMP384 has a gel-filled cavity that allows higher robustness against water, liquids and other chemicals if the applicable integration concept is used. The BMP384 is perfectly suitable for applications of water-level and clog detection. It is compatible for use with other Bosch Sensortec sensors, including the BMI088 for better performance, robustness and stability. The BMP384 with its small footprint offers outstanding design flexibility, providing a single package solution that is easy to integrate into other existing and upcoming devices for smart homes, industrial products and wearables.
Technical data
| Parameter | Technical data |
|---|---|
|
Parameter
Package dimensions
|
Technical data
2.0 x 2.0 x 1.0 mm³ metal lid LGA
|
|
Parameter
Operation range
|
Technical data
Pressure: 300... 1250 hPa
|
|
Parameter
Supply voltage VDDIO
Supply voltage VDD |
Technical data
1.2 V ... 3.6 V
1.65 V ... 3.6 V |
|
Parameter
Interface
|
Technical data
I²C (up to 3.4 MHz) and SPI (3 and 4 wire, up to 10 MHz)
|
|
Parameter
Average typical current consumption (1 Hz data rate)
|
Technical data
3.4 µA @ 1 Hzpressure and temperature,
2.0 µA in sleep mode |
|
Parameter
Absolute accuracy
P=300 ...1100 hPa (T=0 ... 65 °C) |
Technical data
± 50 Pa |
|
Parameter
Relative accuracy pressure (typ.)
P=900…1100 hPa (T=25 … 40°C) |
Technical data
± 9 Pa, equiv. to ± 0.75 m
|
|
Parameter
Noise in pressure (lowest bandwidth, highest resolution)
|
Technical data
0.03 Pa
|
|
Parameter
Temperature coefficient offset (25°…40°C @ 900 hPa)
|
Technical data
±1 Pa/K
|
|
Parameter
Long-term stability (12 months)
|
Technical data
±0.70 hPa
|
|
Parameter
Solder drift
|
Technical data
< ± 1.75 hPa
|
|
Parameter
Maximum sampling rate
|
Technical data
200 Hz
|
